Overview
Talboys Standard High Volume Stirrers are designed for large capacity applications. Powerful magnet and motor offer exceptional magnetic coupling force capable of stirring 25L.
Stirrer is supplied with a 2.75" (7cm) PTFE coated stir bar.
Operating Conditions: Stirrer can be run in conditions from 5 to 40°C (41 to 104°F), 20% to 80% relative humidity, non-condensing. Stirrer includes a 5 year, industry leading limited warranty on parts and labor.
Features:
- Powerful motor and magnet mix up to 25L of liquid
- Large top plate surface
- Microprocessor controls
- 5 year industry leading warranty
| Microprocessor Control |
Precisely regulates speed through the entire range. Stirring function, with continuous duty motor and magnet, maintains speed even under changing load or viscosity. |
| Adjustment Knobs |
Basic speed control knob with dial markings from 1 to 10. (Standard Series) |
| Top Plate Material |
Features a chemical resistant, reflective white top plate surface that is easy to clean. |
| Low Profile Design |
Takes up minimal space. Spill-resistant housing channels fluids away from internal components. Cast aluminum base offers durability and added stability. |
| Speed Ramping Feature |
Slowly increases speed for improved safety and enhanced coupling. Avoids splashing, improves spin bar control and provides excellent low speed control. |
Key Attributes
| Maximum volume (L): |
25 |
| Minimum Volume (L): |
N/A |
| Speed max (rpm): |
1400 |
| Speed min (rpm): |
60 |
| Max temperature (◦C): |
N/A |
| Plate: |
Square |
| Plate material: |
Glass filled nylon |
| Torque max (Ncm): |
N/A |
| Controls: |
Analog |
| Timer: |
No |
| Programmable: |
No |
| Reverse rotation: |
No |
| Warranty (years): |
5 |
| Weight (lbs): |
N/A |
| Dimensions Width (in): |
11 |
| Dimensions Length (in): |
17 |
| Dimensions Height (in): |
4 |
Manufacturer Specifications
| Control Type |
Digital |
| Unit Type |
High Volume Stirrers |
| Frequency |
50 / 60 Hz |
| Voltage |
120V |
| Amps |
1.3 |
| Watts |
75 |
| Top Plate Material |
Glass Filled Nylon |
| Top Plate Dimensions |
12.5 x 11" (31.8 x 27.9cm) |
| Speed Range |
60 to 1400 rpm |
| Speed Stability |
60 to 250 rpm ± 5rpm, 250 to 1400 rpm ± 2% |
| Timer |
N/A |
| Maximum Capacity H2O |
25L |
| Maximum Vessel Diameter |
10" (25cm) |
| Dimensions |
17 x 11 x 4" |
| Operating Conditions |
Units can be run in conditions from 5 to 40°C (41 to 104°F), 20% to 80% relative humidity, non-condensing. |
| Applications |
Carboys, chromatography, and large volume sample stirring. |
| Certifications |
UL Listed |
| Warranty |
5 year industry leading limited warranty on parts and labor |
| Unit Supplied With |
Unit includes a 92" (234cm) detachable, 3-wire cord and plug. Unit is also supplied with a 2.75" (7cm) PTFE coated stir bar. |
